- Application
It is used to transport and absorb greasy foods such as milk and edible oil, as well as non-greasy foods such as beer, red wine and other liquid foods. It complies with FDA food grade certification.
- Technical parameters
Inner layer: food grade NBR synthetic rubber, white, smooth
Reinforcement layer: high-strength synthetic cord plus spiral steel wire reinforcement
Outer layer: anti-aging and grease-resistant synthetic rubber, red, surface texture
- Working temperature:
-20℃ to +80℃ (-4oF to +176oF)
- Applicable standards and certifications:
FDA 21, CFR 177.2600
|
product code |
Inner diameter |
Outer diameter |
Work pressure |
Burst pressure |
Resistant to negative pressure |
Packing length |
|
|
No. |
(in) |
(mm) |
(mm) |
(bar) |
(bar) |
(bar) |
(m) |
|
A5-001-0500 |
1/2″ |
12.7 |
twenty four |
10 |
30 |
0.9 |
60 |
|
A5-001-0750 |
3/4″ |
19.7 |
32 |
10 |
30 |
0.9 |
60 |
|
A5-001-1000 |
1″ |
25.4 |
38 |
10 |
30 |
0.9 |
60 |
|
A5-001-1250 |
1-1/4″ |
31.8 |
46 |
10 |
30 |
0.9 |
60 |
|
A5-001-1500 |
1-1/2″ |
38.1 |
52 |
10 |
30 |
0.9 |
60 |
|
A5-001-2000 |
2″ |
50.8 |
66 |
10 |
30 |
0.9 |
60 |
|
A5-001-2500 |
2-1/2″ |
63.5 |
80 |
10 |
30 |
0.9 |
60 |
|
A5-001-3000 |
3″ |
76.2 |
93 |
10 |
30 |
0.9 |
60 |
|
A5-001-4000 |
4″ |
101.6 |
120 |
10 |
30 |
0.9 |
60 |
